    Ürün ayrıntıları:

    Menşe yeri: Çin
    Marka adı: BRITEC
    Model numarası: BR-12.5M 275 3 + 1

    Ödeme & teslimat koşulları:

    Min sipariş miktarı: 100 Adet / Adet
    Ambalaj bilgileri: İHRACAT AMBALAJ
    Teslim süresi: Ödeme yapıldıktan sonra 15 gün içinde sevk
    Ödeme koşulları: L / C, D / A, T / T, Western Union
    Yetenek temini: 50000 Adet / Adet Ay
    İletişim
    Detaylı ürün tanımı
    öğe adı: Parafudr Place of Originfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translate: Zhejiang, Çin (anakara)
    Marka adı: BRITEC Türü:
    Malzeme: Öğe yazın: Güç yıldırım koruması
    Renk: Beyaz UC: 275v
    Iimp: 12.5kA Kullanım: Düşük voltaj
    Teslim süresi: 15-30days Standart: IEC 61643-1function gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage(
    Vurgulamak:

    lightning protection device

    ,

    lightning surge protector

    AC 275v Type 3pole+NPE Power Lightning Protection Class 1+2 Surge Arrestors



    Feature:



    Class I+II, Class B+C 12.5kA high discharge capacity TT and TN-S system lightning protector.
    Designed according to IEC 61643-1.
    Pluggable module, high discharge capacity, quick response.



    Technology characteristic:



      BR-12.5M 275 3+1
    Max. continuous operating a.c. voltage                             Uc 275V
    Lightning impulse current (10/350us)                              Iimp 12.5kA
    Max. discharge current (8/20us) (L-N/N-PE)                  Imax 50kA / 70kA
    Voltage protection level (L-N/N-PE)                                   Up ≤1.3kV / ≤1.5kV
    Response time (L-N/N-PE)                                                 tA ≤25ns / ≤100ns
    Max. backup fuse 160A
    Operating temperature range                                             Tu -40℃—80℃
    Cross-section area (Min.) 4mm2
    Cross-section area (Max.) 35mm2
    For mounting on 35mm Din rail
    Enclosure material                Thermal plastic UL94-V0
    Dimension 4mods
    Test standards IEC 61643-1



    Dimension:



    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0



    Application:

    Designed to protect low voltage devices from surge damage, mainly used in power supply system such
      as power distribution room, distribution cabinet and other important power supply system, specially
      designed for TT and TN-S system.
    Applied in SPD Class I+II (Class B+C) for power supply system of lightning current surge protection.

    Certificate:

    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    Shipping:

    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    Payment:

    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    Production Flow:

    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    Test Facilities:

    In order to test its products internally for standards compliance and to evolve toward greater reliability
    we has test site.

    AC 275v Type 3 Pole + NPE Power Lightning Protection Class 1+2 Surge Arrestorsfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    FAQ:

    Q1: What's your warranty?
    A1: The warranty is 2 years and we deliver new and faultless products.


    Q2: What's the standard of package?

    A2: Inner box and out carton are made as per international standard and we can make special design

          according to customer's need.



    Q3: Could you do OEM for us?
    A3: Sure,OEM is acceptable, and please supply with the brand letter of Authorization.
