Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arresterfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});}

Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arresterfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});}

    • Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arrester
    • Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arrester
  • Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arrester

    Ürün ayrıntıları:

    Menşe yeri: Çin
    Marka adı: BRITEC
    Model numarası: BR-20275 1 + 1

    Ödeme & teslimat koşulları:

    Min sipariş miktarı: 100 Adet / Adet
    Ambalaj bilgileri: İHRACAT AMBALAJ
    Teslim süresi: Ödeme yapıldıktan sonra 15 gün içinde sevk
    Ödeme koşulları: L / C, D / A, T / T, Western Union
    Yetenek temini: 50000 Adet / Adet Ay
    İletişim
    Detaylı ürün tanımı
    öğe adı: Akım koruması Malzeme: Thermal Plasticfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translateP
    Kutup sayısı: 1P + NPE Brand name: Britec
    koruma: IP20 içinde: 10kA
    : -40℃-80℃ UC: 275vfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', '
    Imax: 20KA Model numarası: BR-20275 1 + 1
    Kullanım: Düşük voltaj UP: ≤1.2kVfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en',
    Vurgulamak:

    lightning protection device

    ,

    lightning surge protector

    Class C Surge Protection Unit AC 275V 20kA Lightning Surge Arrester



    Features:

    • Pole No.: 1P+NPE.
      Frequency: 50/60Hz.
      Standards: IEC61643-1.
      In case of surge current or voltage caused by lightning strike or similar, SPD functions quickly
    •   conduct the surge voltage/current to earth and thus effectively prevent the downstream
    •   equipment of its protected line from destruction.
      Green: normal function; Red: functionless, immediate replacement required.


    Technology characteristic:



      BR-20 275 1+1
    No. of poles 1P+NPE
    Power supply system TT and TN-S system
    SPD classification according to IEC61643-11 Class II
    Max. continuous operating a.c. voltage               Uc 275V
    Voltage protection level                                        Up ≤1.2kV
    Max. discharge current (8/20us)                       Imax 20kA
    Nominal discharge current (8/20us)                      In 10kA
    Operating state / fault indication green / red
    Remote contacts Optional
    Response time                                                      tA ≤25ns
    Operating temperature range                               Tu -40℃—80℃
    Relative humidity    On condition that room temperature 30% to 90%
    Enclosure material Thermal plastic UL94-V0
    Degree of protection IP20
    For mounting on 35mm Din rail
    Test grade IEC61643-1 standards



    Dimension:



    Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arresterfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0



    Application:



    Provide protection against surge current resulted from direct or indirect lightning strike or similar surge voltage.



    Certification:



    Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arresterfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0



    Work Shop:



    Class C Power Surge Protection Device AC 275V 20kA Lightning Surge Arresterfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0



    FAQ:



    Q1: When I can receive quotation and detail information after send the enquiry?
      A: Reply will be sent in 24hours.



    Q2: Do you provide samples? Is it free or extra?
      A: Yes, we could provide samples, but it is not free.



    Q3: Can I get a sample for test before place order?
      A: Of course!



    Q4: How's the delivery? Because I really need them is urgently?
      A: Samples cost 7-10 days. Bulk order cost 15-30 days.



    Q5: If I want to release order, what's the payment method you accept ?
      A: We accept T/T, Paypal, L/C etc.
